Wall-Mounted Home Energy Storage 10.24KWH

Electrical Characteristics

Rate Voltage

51 .2VDC

Rate Capacity

200Ah

Energy Storage

10 .24kWh

Cycle Life

>6000 cycles to 85% DOD

Months Self Discharge

≤2%

Efficiency of Charge

100% at 0 .2C

Efficiency of Discharge

96-99% at 1C

Standard Charge

Standard Charge Current

40

Charge Voltage

0 .2C to 54 .2V, then 58 .4V charge current to 0 .02C( DC/ DC)

Charge Mode

40A

Max .Charge Current

100A

Standard Discharge

Contiunous Current

100A

Discharge cut-off Voltage

44 .8VCD

Temperature

Charge Temperature

0℃ to 45℃ (32F to 113F)@60+25% Relative Humidity

Discharge Temperature

-20℃ to 60 ℃(-4F to 140F)@60+25% Relative Humidity

Storage Temperature

-20℃ to 60 ℃(-4F to 140F)@60+25% Relative Humidity

Mechanical

IP Class

IP60

Meteria

LiFePO4

Case Material

Metal

Case Type

Rack Wall Mount

Size

750*485*210(mm)

Weight

90KG

Terminal

M8

Protocol(optional)

CANBUS/ RS485/ RS232

SOC(optional)

LED/ LCD

The quality assurance period

60 months
